2005 Chevrolet Equinox Problems



2005 Equinox Problems

The purpose of this page is to help you quickly identify the most common problems with the 2005 Chevrolet Equinox.  The content is divided into () main sections.  Both the 2005 and 2006 Chevy Equinox are known to have some serious problems.  If you have made your way to this page trying to figure out if you should pick one up, we’d recommend that you go with an ’07 or newer model.

Navigation:

Common Problems

Engine Problems

Transmission Problems

Non-Drivetrain Related Problems

Recalls

Select Technical Service Bulletins

Most Common Issues with the 2005 Equinox

  • Blown head gasket–  The head gasket on these engines (and the 2006) are well known the head gasket failing without overheating.  Since it will fail without overheating, there’s no warning. It just happens.  That’s why if you are using this guide to ascertain whether or not to buy an 05 Equinox, we’d recommend you pass for a 07+ model year.
  • Failing A/C Compressor–  The A/C compressor on the Equinox is prone to failure.  While it won’t leave you stranded, it can still be an expensive repair.
  • Ignition/Key–  One of the most common problems, and the only recall item on the 2005 Equinox is the ignition and key.  The vehicle can potentially fail to go into park.  The key can also fall out of the ignition with the vehicle in motion.
  • Gas Cap–  The gas cap on the 05 Equinox is prone to failure.  This will result in the service engine soon light coming on.  It’ll usually read one of the Evaporative Emissions system trouble codes.  It can also become difficult to fill the gas tank.

2005 Equinox Engine Problems + Specs

The 2005 Equinox was available with one engine.  It was the LNJ V6.  It’s power output was 185 hp at the rear wheels and it put out 210 foot pounds of torque, see directly above for more info regarding the engine.  Far and away the biggest area of concern for this engine is with the head gasket.

2005 Chevrolet Equinox Engine Specs
Type 3.4L V-6
Block Iron
Heads Aluminum
Ignition Coil on Plug
Fuel Delivery Sequential Multi Port Fuel Injection
Horsepower 185 @ 5200 RPM
Torque 210 ft lb @ 3800 RPM
Compression 9.5:1

Source:  https://www.gmheritagecenter.com/docs/gm-heritage-archive/vehicle-information-kits/Equinox/2005-Chevrolet-Equinox.pdf



Blown Head Gasket

One of the most common 05 Chevy Equinox problems is the blown head gasket.  It’s a known problem.  For a lot of people, it seems to strike without warning.  That is to say the head gasket will blow without overheating occurring.   If there’s no record of the Equinox that you are considering buying being brought in for this service, consider that a red flag.



Bad Battery Posts

It is very common for the battery connection to corrode.  This will lead to the motor not starting.  This is a well known issue.



Bad A/C Compressor

The 2005 Equinox is prone to A/C failure.  As a fifteen year old vehicle, it may be worth checking the A/C before buying one.

2005 Equinox Transmission Problems + Info

The 05 Equinox was equipped with the Aisin AF33 transmission.  It was made in China and found it’s way into not only General Motors vehicles, but also Volvos, Suzukis, Renaults, and Nissans.

It is considered to be a fill for life transmission.  That means that as long as it is operated under normal conditions, it will not require any transmission fluid change.



Gear Ratios

The AF33 equipped in the 05 Equinox has is not a true overdrive transmission.  It’s final gear ratio is a 1:1 direct drive ratio.  The necessary fuel economy is achieved through a very modest 2.65 final drive ratio.

05 Equinox Gearing 1ST 2ND 3RD 4TH 5TH REVERSE
4.68 2.94 1.92 1.30 1.00 3.18

Identification

If you’d like to confirm that the transmission in your Equinox is the AF33, go ahead and pop open the glove compartment.  You’ll want to check out the RPO codes in the glove compartment.  You’ll either have the FWD or AWD version of this transmission.  Find these codes on the tag to tell you which one that you have.

  • M09-  Front Wheel Drive
  • M45-  All Wheel Drive

Here is a list of some of the most common problems with the AF33 transmission that is equipped in the 05 Equinox.

No Torque Converter Lock Up

The locking clutch on the torque converter is a known area of weakness with this transmission.  It is well known that the clutch is a little to small for many applications.

When the torque converter refuses to lock up gas mileage suffers.  The vehicle will also travel down the highway at a higher RPM.  If you ever drove an older American car with an automatic transmission, you’ll know the feeling.  You hit the gas and the rpm rises, even though the transmission isn’t downshifting.

No Forward Gears at All

A surprisingly common problem with the AF33 is the loss of all forward gears at one time.  This is usually caused by a loss in line pressure.  Common causes of this problem include:

  • Bad front pump
  • Bad pressure regulator
  • Valve body (valve stuck)

Fluid Leak

It’s common for any transmission to develop a leak with enough mileage under it’s belt.  Some common areas that the Equinox’s transmission leaks from are:

  • Pan gasket
  • Torque converter hub

Faulty Solenoids

Solenoids are devices that are used to control the flow of transmission fluid throughout the the transmission.  There are many solenoids in the AF33.  When one goes bad, the Equinox can not properly operate.  A solenoid repair is not the most expensive repair.  But, it can take some work to get to it.



Drivetrain- Other

Here are the problems with the vehicle that can keep it from running that have nothing to do with the engine or transmission, but would still keep the vehicle from potentially running and driving.

Ignition Issues/Key

There is a well known problem with the 2005 Equinoxes ignition system.  The key has been known to fall right out of the ignition while going down the road, or get stuck in the cylinder.

NHTSA Recalls

There was only one recall on the 2005 Equinox, and it wasn’t for the head gasket, it was for the ignition key/lock.  More info below.

GM Recall No. 04044:  Ignition Key Park

The ignition key park lock cable can keep the shifter from going all of the way into the park position.  Here is a link to the recall itself.



Select Technical Service Bulletins

There are many technical service bulletins on the 2005 Equinox.  Listed here are a few of the most common and serious ones.  They are still being issued regularly.  If you are interested in the full list, here you go.

EGR Pintle Stuck:

This will usually be accompanied by the trouble code P0404 or P1404.

NHTSA ID: 10018579
GM:  3636
TROUBLE CODE:  P0404, P1404
Affected Years:  2005-2006



Evap Vent Restriction

The evaporation vent on the equinox can be restricted.  Under this condition the engine will often throw the P0446 trouble code.

NHTSA:  10010555
GM:  3163
Trouble Code:  P0446
Affected Years: 2005



Misfire, Rough Idle, No Start

This set of conditions can certainly happen to any vehicle with no mileage on it.  GM recommends that the technician run a diagnostic and see if there is carbon build up on the upper engine.  The recommended solution is valve cleaning.

Related to:

NHTSA ID: 10114746, 10113418
GM:  PIP5029F



Iced Motor

In the coldest of conditions the intake and induction system has been know to ice up.  There is an official procedure to let the ice melt out.

Related to NHTSA: 10129073

GM TSB: PIP5540A



Valve Train Noise/Low Compression

Valve Train noise on the 05 Equinox is often a symptom of low cylinder compression.

NHTSA:  10007735
GM:  02049
Trouble Code:  P0300
Affected Years: 2005
Issued:  1/1/04
